- General Information
- Manufacturer
- Kramer Electronics LTD
- Manufacturer Website Address
- http://www.kramerelectronics.com
- Brand Name
- Kramer
- Product Type
- KVM Switchbox
DK22D-3 is a secure dual head 2-port, 4K30 UHD DVI-I KVM switch. It enables users to share peripherals - keyboard, video, mouse and audio - between two different security-level networks/computers while isolating all hosts and protecting against data leakage and malicious attacks through shared peripherals. DK22D-3 provides the highest possible isolation between connected computers and is NIAP Common Criteria Protection Profile version 3.0 (PP3.0) certified
FEATURES
Highest Security by Design - NIAP Common Criteria Protection Profile version 3.0 (PP3.0) certification for peripheral Sharing Switch (PSS) devices
4K30 UHD Resolution - Supports resolutions up to 3840×2160 @30Hz
Work Freely Without Compromising Security - Display and control classified and non-classified computers without compromising security
Prevent Information Leaks - Block peripheral exploits, information leaks, eavesdropping, signal transmission, computer malware, hardware and firmware tampering
Dual Display - Provides flexible presentation options with duplicate or extend view modes
Smooth Switching Between Computers (Virtual Display Technology) - Automatically switch all peripheral control from one computer to another by dragging the cursor between each computer's display border
Keyboard Lock Indication - Caps Lock, Num Lock, and Scroll Lock indication on front panel
Versatile and Flexible - Configurable as a KVM switch (default) for sharing a display, keyboard and mouse between connected computers, or KM switch for sharing keyboard and mouse and simultaneously working on multiple computers connected to separate displays
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Number of Computers Supported
- 2
- Number of Local Users Supported
- 1
- Features
- LED Indicator
- Virtual Display Technology
- Video
- Maximum Video Resolution
- 3840 x 2160
- Interfaces/Ports
- USB
- Yes
- DVI
- Yes
- Number of USB Ports
- 4
- Number of DVI Ports
- 6
- Power Description
- Input Voltage Range
- 100 - 240V
- Physical Characteristics
- Height
- 2"
- Width
- 7"
- Depth
- 3.6"
- Weight (Approximate)
- 1.32 lb
- Miscellaneous
- Compatibility
- Windows
- Linux
- Mac
