- General Information
- Manufacturer
- PANDUIT CORP
- Manufacturer Website Address
- http://www.panduit.com
- Brand Name
- Panduit
- Product Series
- G6
- Packaged Quantity
- 1 Piece
- Product Type
- PDU
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- PDU Type
- Monitored
- Switched
- Phase
- Three Phase
- Plug/Connector Type
- CS8365
- Receptacle Type
- IEC 60320 C13/C19
- Receptacle Detail
- 30 x IEC 60320 C13
- 6 x IEC 60320 C19
- Features
- SNMP Compatible
- LED Status Indicator
- Load Capacity (VA)
- 10 kW
- Load Capacity (Watt)
- 10 kW
- Power Description
- Input Voltage
- 208 V
- Output Voltage
- 208 V AC
- Power Rating (VA)
- 10000 VA
- Input Current
- 50 A
- Input Frequency
- 50 Hz
- Circuit Breaker
- Yes
- Number of Circuit Breakers
- 3
- Voltage Measurement Accuracy
- ±1%
- Current Measurement Accuracy
- ±1%
- Management
- Management
- SNMP
- Network Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- USB
- Yes
- Network Monitoring Port Detail
- Gigabit network port reduces labor by auto negotiating with data center level network switches
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Product Material
- Metal
- Mounting Orientation
- Vertical
- Mount Type
- Rack-mountable
- Rack Height
- 0U
- Cord Length
- 10 ft
- Height
- 69"
- Width
- 2"
- Depth
- 2.1"
- Environmental Conditions
- Minimum Operating Temperature
- 50°F (10°C)
- Maximum Operating Temperature
- 140°F (60°C)
- Minimum Storage Temperature
- 24.8°F (-4°C)
- Maximum Storage Temperature
- 284°F (140°C)
- Miscellaneous
- Package Contents
- G6 MS PDU, 10KW, 50AMP, (30)C13, (6)C19, CS8365
- Mounting Hardware
- Additional Information
- Cascade up to 32 PDUs
- Use display to set IP address, update firmware, quick configure, rotate display, balance loads across phases, view alarms, read current, voltage, power and energy on the device
- Application/Usage
- Data Center
- Switch
- Certifications & Standards
- UL 62368-1
- FCC Pat 15 Class A (USA)
- NOM (Mexico)
- RETIE (Colombia)
- Country of Origin
- India
- Environmentally Friendly
- Yes
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
- UL Listed
- Yes
