- General Information
- Manufacturer
- Eaton Corporation
- Manufacturer Website Address
- http://www.eaton.com
- Brand Name
- Eaton
- Product Series
- G4
- Product Type
- PDU
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- PDU Type
- Managed
- Phase
- Single Phase/Three Phase
- Plug/Connector Type
- Universal Input
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C39
- Receptacle Detail
- 18 x IEC 60320 C13
- 18 x IEC 60320 C19
- Protection Type
- Overload Protection
- Features
- LCD Display
- Load Capacity (VA)
- 23 kW
- Load Capacity (Watt)
- 23 kW
- Power Description
- Input Voltage
- 230 V AC
- 400 V AC
- Input Voltage Range
- 200 V AC - 415 V AC
- Input Current
- 55 A
- Input Frequency
- 60 Hz
- Circuit Breaker
- Yes
- Management
- Remote Outlet Switching
- Yes
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Physical Characteristics
- Mount Type
- Rack-mountable
- Form Factor
- Rack
- Rack Height
- 3U
- Miscellaneous
- Application/Usage
- IT Equipment
- Certifications & Standards
- cTUVus
- 2014/35/EU: LVD - Low Voltage Directive
- 2014/30/EU: EMC - Electromagnetic Directive
- 2011/65/EU (2015/863 included)
- EN 62368-1:2014
- EN IEC 61000-6-2:2019
- EN IEC 61000-6-4 :2019
- EN 61000-3-2:2014
- EN 61000-3-12:2011
- EN 61000-3-3:2013
- IEC 61000-3-11:2019
- EN IEC 63000: 2018
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
