Club 3D MST Hub DisplayPort 1.4 to DisplayPort + HDMI 4K60Hz M/F

  • Part: 3205179
  • Model: CSV-7220
$51.00

Availability

Out of Stock

  • General Information
    • Manufacturer
    • Club 3D
    • Manufacturer Website Address
    • http://www.club-3d.nl
    • Brand Name
    • Club 3D
    • Product Type
    • A/V Adapter

The CSV-7220 is a MST hub DisplayPort™ 1.4 to DisplayPort™ + HDMI™ 4K60Hz M/F. This DisplayPort™ 1.4 MST hub is designed to cater for your most versatile connectivity demands, such as tablets, laptops, etc. with a free DP™ (DisplayPort) port.


Give your device more displays. PCs and notebooks are increasingly becoming more powerful and smaller in the physical form factor. With a single DP™1.4 port available you can now drive one-Displayport™ screen simultaneously with an HDMI™ screen at 4K60Hz or One DP™ display at 8K30Hz in MST mode Windows. All it needs is a free DP™ 1.4 port on your Laptop or PC to connect to the MST hub and will provide you with unparalleled connection options for Dual 4K60Hz displays. The setup is easy and simple to do, provided your system supports DP1.4 specifications and DSC1.2 Compression, resolutions can be limited if the source device is lower. The CSV-7220 is externally powered by a USB Type-A to Micro USB cable which comes with the product.

Share



  • Technical Information
    • Adapter Type
    • DisplayPort/HDMI
    • Connector Type on First End
    • DisplayPort 1.4 Digital Audio/Video - Male
    • Micro USB - Female
    • Connector Gender on First End
    • Male
    • Connector on First End Details
    • 1 x DisplayPort 1.4 Digital Audio/Video -Male
    • 1 x Micro USB - Female
    • Connector Type on Second End
    • DisplayPort 1.4 Digital Audio/Video - Female
    • HDMI Digital Audio/Video - Female
    • Connector Gender on Second End
    • Female
    • Connector on Second End Details
    • 1 x DisplayPort 1.4 Digital Audio/Video - Female
    • 1 x HDMI Digital Audio/Video - Female
    • Maximum Resolution Supported
    • 3840 x 2160
    • Features
    • Multi-Stream Transport (MST) Support
    • HDCP 2.2
    • Single Stream Transport (SST)
  • Physical Characteristics
    • Product Color
    • Black
  • Miscellaneous
    • Package Contents
      • MST Hub DisplayPort 1.4 to DisplayPort + HDMI 4K60Hz M/F
      • USB Type-A to Micro USB Power Cable 1m /3.28 ft
    • Environmentally Friendly
    • Yes
    • Environmental Compliance
    • Restriction of Hazardous Substances (RoHS)
