- Supports HDMI, 3.5-mm analog audio, and TOSLINK optical audio inputs and outputs.
- Supports resolutions of up to 4K at 60 Hz in 4:4:4 color.
- Embeds audio from either a 3.5-mm or optical source to an HDMI or DVI-D signal.
- Create audio channels where there was not an existing one.
- De-embed audio from HDMI signal and output it to 3.5-mm analog or digital optical sound systems.
- Can de-embed audio without being connected to an HDMI display.
- Supports embedding and de-embedding at the same time.
- Controlled through simple DIP switch configuration.
- General Information
- Manufacturer
- Black Box Corporation
- Manufacturer Website Address
- http://www.blackbox.com
- Brand Name
- Black Box
- Packaged Quantity
- 1
- Product Type
- Signal Extractor
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Functions
- Audio Embedding
- Audio De-embedding
- Interfaces/Ports
- USB
- Yes
- HDMI
- Yes
- Audio Line In
- Yes
- Audio Line Out
- Yes
- Physical Characteristics
- Form Factor
- Mountable
- Height
- 1"
- Width
- 3.7"
- Depth
- 2.6"
- Weight (Approximate)
- 0.57 lb
- Miscellaneous
- Package Contents
- Audio Embedder/De-embedder - HDMI 2.0
- 1 x 5-Volt, 4-Amp Power Supply with Adapter Clips
- 2 x Mounting Screws
- User Manual
- Country of Origin
- Taiwan
- TAA Compliant
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS) 2
- Waste Electrical and Electronic Equipment Directive (WEEE)
