APC by Schneider Electric Symmetra LX 16000VA Tower UPS

  • Part: 1011885
  • Model: SYAF16KXR9T
$10,280.00

Availability

Out of Stock

  • General Information
    • Manufacturer
    • Schneider Electric SA
    • Manufacturer Website Address
    • http://www.schneider-electric.com
    • Brand Name
    • APC by Schneider Electric
    • Product Line
    • Symmetra LX
    • Packaged Quantity
    • 1 / Pack
    • Product Type
    • Double Conversion Online UPS
  • Warranty
    • Limited Warranty
    • 2 Year
    • Additional Warranty Information
    • 2 years repair or replace

  • Technical Information
    • Plug/Connector Type
    • Hard Wire 4-wire (2PH+N+G)
    • Receptacle Type
    • Hard Wire 4-Wire (2PH + N +G)
    • Receptacle Detail
    • 1 x Hard Wire 4-wire (2PH+N+G)
    • Application/Usage
    • Server
    • Telecommunication
    • Efficiency
    • 90%
  • Power Description
    • Load Capacity (VA)
    • 16 kVA
    • Load Capacity (Watt)
    • 12.80 kW
    • Input Voltage
    • 230 V AC
    • Input Voltage Range
    • 230 V AC - 415 V AC
    • 155 V AC - 276 V AC
    • Output Voltage
    • 240 V AC
    • 120 V AC
    • 208 V AC
    • Input Frequency
    • 45 Hz
    • 65 Hz
    • Output Frequency
    • 47 Hz
    • 63 Hz
    • 50 Hz
    • 60 Hz
    • Waveform Type
    • Sine Wave
  • Display & Graphics
    • Display
    • LCD
  • Management
    • Network Management
    • Network Management Card
  • Interfaces/Ports
    • USB
    • No
    • EPO Port
    • Yes
  • Battery Information
    • Battery Chemistry
    • Lead Acid
  • Environmental Conditions
    • Maximum Operating Temperature
    • 104°F (40°C)
    • Maximum Operating Elevation
    • 10000 ft
    • Maximum Storage Elevation
    • 15000 ft
    • Storage Relative Humidity
    • 0% - 95%
    • Sound Emission (A-Weighted)
    • 62 dB(A)
    • Thermal Dissipation
    • 1463.89 W
  • Physical Characteristics
    • Color Family
    • Dual Color
    • Product Color
    • Black
    • Silver
    • Form Factor
    • Tower
    • Mounting Location
    • Front
    • Mounting Preference
    • No Preference
    • Height
    • 36.9"
    • Width
    • 19"
    • Depth
    • 28.6"
    • Weight (Approximate)
    • 400.84 lb
  • Miscellaneous
    • Package Contents
      • Symmetra LX 16000VA Tower UPS
      • CD with Software
      • Installation Guide
      • User Manual
      • Web/SNMP Management Card
    • Certifications & Standards
      • CSA
      • CC Part 15 class A
      • UL 1778
    • Environmental Compliance
    • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
    • Restriction of Hazardous Substances (RoHS)
