- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Smart-UPS
- Product Type
- Line-interactive UPS
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
- 3 years repair or replace (excluding battery) and 2 years for battery
- Technical Information
- Plug/Connector Type
- NEMA 5-15P
- Receptacle Type
- NEMA 5-15P
- Receptacle Detail
- 8 x NEMA 5-15R
- Number of Battery & Surge Outlets
- 8
- Transfer Time
- 10 ms
- Application/Usage
- Network Device
- POS
- Server
- Security System
- Communication System
- Power Description
- Load Capacity (VA)
- 1440 VA
- Load Capacity (Watt)
- 1000 W
- Input Voltage
- 120 V
- Input Voltage Range
- 82 V AC - 144 V AC
- Output Voltage
- 120 V AC
- Input Frequency
- 60 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 693 J
- Management
- Alarm
- Alarm
- Controls/Indicators
- Status Indicators
LED status display:
- Load bar-graphs
- Battery bar-graphs
- On line
- On battery
- Replace battery
- Overload indicators
- Interfaces/Ports
- USB (HID Compliant) Port
- Yes
- Battery Information
- Number of Batteries
- 1
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 5 Minute
- Backup/Run Time (Half Load)
- 17 Minute
- Battery Life
- 5 Year
- Typical Battery Recharge Time
- 3 Hour
- Environmental Conditions
- Maximum Operating Temperature
- 104°F (40°C)
- Storage Temperature
- -4°F (-20°C) - 131°F (55°C)
- Storage Relative Humidity
- 0% - 95%
- Sound Emission (A-Weighted)
- 45 dB(A)
- Thermal Dissipation
- 65.94 W
- Physical Characteristics
- Height
- 8.6"
- Width
- 6.7"
- Depth
- 17.3"
- Form Factor
- Tower
- Mounting Location
- Front
- Weight (Approximate)
- 54.23 lb
- Miscellaneous
- Certifications & Standards
- CSA C22.2 No 107.1
- Green Premium
- Yes
- Mercury Free
- Yes
- RoHS Exemption Information
- https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMT1500X93_ROHS_DECLARATION&p_FileName=SMT1500X93KIT_ROHS_DECLARATION_US.pdf
- REACH Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=559241381&lang=en-us
- EU RoHS Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=559241381&lang=en-us
- Environmental Profile Availability
- https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612029_EN
- End of Life Manual Availability
- https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612029_EN
- REACH free of SVHC
- No
- WEEE Statement
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Country of Origin
- United States
- TAA Compliant
- Yes
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
